Medical Borescope Camera
The Medical Borescope Camera is a 4K imaging platform for minimally invasive surgery and medical endoscope integration. It combines real-time 4K imaging, automatic exposure control, multiple video outputs, image adjustment functions, and electrical protection in one camera control unit.
Product Overview
The Medical Borescope Camera is a 4K imaging platform for minimally invasive surgery and medical endoscope integration. It combines real-time 4K imaging, automatic exposure control, multiple video outputs, image adjustment functions, and electrical protection in one camera control unit.
4K Surgical Imaging
Detailed Real-Time Visualization
The 1/1.8-inch 4K CMOS sensor provides detailed surgical images for intraoperative visualization and supports clear observation of fine structures.
Stable Motion Imaging
50/60-frame operation provides smooth live video during endoscope movement, helping reduce visible trailing during dynamic procedures.
Automatic Image Adjustment
Auto aperture, shutter, and gain control continuously adjust exposure according to illumination changes, reducing the need for manual correction during surgery.
Parameters
|
Synchronization mode |
Internal synchronization |
|
Resolution ratio |
3840*2160P,analog:1600 TV lines |
|
Frame rate |
50/60 frames |
|
Signal to noise ratio |
Not lower than 50dB (AGC off) |
|
Video output |
4K: HDMIX13G-SDI(Level A)x4 BNC1ch, HDTV: DVI1ch, HD-SDI2ch |
|
Sensitivity |
2000lxF11/3200Kor more(LINEMIXON) |
|
OSD menu |
Available |
|
White balance |
Button |
|
Screen freezing |
Button |
|
Rated power |
Up to 29W |
|
Applicable standard |
GB9706,YY0505,GB/T14710,CE,ROHS |
|
Temperature range |
Operating temperature) -20'C~+55C (storage temperature |
|
Net weight |
4.6Kg |
|
Dimensions |
380mmX300mmX115mm |
Properties
|
Menu |
Range |
Default value |
|
Electronic shutter |
Manual/Auto/Slow |
Auto |
|
Automatic gain control |
-9dB~24dB |
0 |
|
Auto aperture sampling |
Narrow / Middle / Full / Circle / USER |
Full |
|
Image flip |
Horizontal, Vertical |
OFF |
|
Digital zoom |
1.1x-4x |
1x |
|
Image level indication |
7 steps(by LED display on CCU) |
4 |
Practical Surgical Controls
One-Touch White Balance
The dedicated white-balance function allows quick image correction when illumination conditions change.
Flexible Image Viewing
Horizontal/vertical image flip and 1.1×–4× digital zoom allow operators to adjust image orientation and viewing scale during procedures.
Image Freeze
The freeze function captures the current displayed image for temporary observation without stopping the camera system.
Multi-Language OSD
The on-screen menu provides direct access to image and system settings with multi-language operation.
Video Output & System Integration
The INP-700 provides 4K, DVI, and HD-SDI outputs for connection with compatible medical monitors, recording devices, and video systems.
Multiple output options allow the camera to be integrated into different operating-room configurations without changing the core imaging platform.
Endoscope Compatibility
The system is designed to work with different medical endoscopes used across clinical departments.
For compatibility evaluation, customers can provide:
• Endoscope model
• Optical configuration
• Required image output
• Existing display system
• Application requirements
This allows the camera configuration to be checked before sampling.
Electrosurgical Equipment Compatibility
The camera incorporates anti-interference design for use alongside compatible high-frequency electrosurgical knives.
The design helps maintain stable video output when electrosurgical equipment is operating during endoscopic procedures.
OEM & ODM Integration
The INP-700 can be supplied for OEM projects requiring integration with existing medical imaging equipment.
Customization can be evaluated for:
Endoscope compatibility
Video interfaces
Image control functions
OSD language
Housing and installation
Product labeling and packaging
Manufacturing & Quality Control
Incoming Component Inspection
Incoming sensors, PCBs, connectors, and optical components are checked against approved specifications through part-number verification, visual inspection, and electrical testing.
Assembly Inspection
After assembly, wiring, connectors, PCB connections, and housing installation are visually inspected and checked for electrical continuity to identify assembly defects.
Image Calibration
Each camera is connected to test equipment and a display to verify image resolution, brightness, color, white balance, and exposure performance. Image parameters are adjusted to meet defined requirements.
Functional Testing
Video outputs, shutter, gain, aperture, image freeze, image flip, digital zoom, and OSD functions are operated and verified individually to confirm normal performance.
Electrical & Protection Testing
Power input and applicable electrical protection functions are tested using calibrated equipment according to the product's specified requirements.
Final Inspection
Before shipment, the finished system is checked for appearance, labeling, accessories, configuration, and overall operation against the approved order requirements.
Traceability
Production and inspection records are retained by product configuration and batch, enabling quality status to be traced when required.
Sample & Procurement Support
Samples are available for customers who need to verify:
Endoscope compatibility
Image performance
Video interface compatibility
Operating-room system integration
Warranty & Long-Term Support
The INP-700 includes a one-year warranty and up to ten years of maintenance assistance.
Technical support covers product configuration, troubleshooting, and maintenance-related requirements during the product lifecycle.
